PH SENSOR
HYTEZ Industrial Grade Glass (Double Junction) pH Sensor
Model: HY-PHS402A
- pH Range: 0 – 14
- Temperature: 0 – 60 ℃
- Pressure Resistance: 3 Bar (Max)
- Body material: PTFE
- Wetted parts: Glass, PTFE
- Slope: > 95%
- Response Time: 3 seconds
- Impedance: 250 MOhms
- Long Term Stability (Drift): < 0.02 pH/ Day
- Thread: PG13.5
- ATC: PT1000 (PT100 available upon request)
- Cable Length: 10m
*Not suitable for sample containing hydrofluoric acid (HF)
Mounting Accessories
PTFE Electrode Protection
Housing with ¾” NPT Thread
Flow Through Chamber
waste water
clean water
PP Electrode Protection
Housing for immersion.
Length: 1m or 2m
